Product General Information:
| Place of Origin | China |
| Brand Name | Jiangsu Xinhe Machinery |
| Model Number | Artificial Marble Corner Line Production Line |
Product Business Terms:
| Minimum Order Quantity | 1 |
| Production Time | 45 days |
| Payment Terms | LC T/T |
Description:
PVC profile production line is composed of a vacuum setting table, a conical twin-screw extruder, a cutting and laminating machine, a tractor, and a turning material. Different specifications of the conical twin-screw extruder can be selected according to different profiles and molds.
Vacuum sizing table: It adopts a special enlarged vortex flow cooling system to facilitate cooling and shaping. According to different molds and sizing tables, 4 meters, 6 meters, 8 meters, 10 meters and other specifications can be selected to meet the requirements of high-speed extrusion.
Extruder: The screw design is adopted to make the polymer micro-foaming plasticized evenly and the output is high. Imported high-quality frequency converters with stable rotation speed are used to ensure the main machine’s and auxiliary machines’ synchronous operation.
Tractor: Adopt lifting technology, stable work, good reliability and large traction.
Cutting machine: The moving speed is synchronized with the tractor, the design is reasonable, the operation is stable, it can be automatically cut to length, and it is equipped with a dust recovery device.
Specifications:
Classic Type Main Technical Parameter
| Model | Extruder model | Product width(mm) | Max capacity(kg/h) | Extruder power(kw) | Cooling water(m³/h) | Compressed air(m³/min) |
| YF108 | 108 | SJZ55/110 | 110 | 22 | 7 | 0.6 |
| YF240 | 240 | SJZ65/132 | 180 | 37 | 8 | 0.6 |
| YF240A | 150*2 | SJZ65/132 | 180 | 37 | 8 | 0.8 |
| YF300 | 300 | SJZ65/132 | 180 | 37 | 8 | 0.6 |
| YF400 | 400 | SJZ80/156 | 320 | 55 | 10 | 0.6 |
High Speed Main Technical Parameter
| Model | Extruder model | Product width(mm) | Max capacity(kg/h) | Extruder power(kw) | Cooling water(m³/h) | Compressed air(m³/min) |
| YF240 | 240 | 150-250 | 45 | 7 | 0.6 | |
| YF240 | 240 | SJZ65/132 | 250-400 | 55 | 8 | 0.6 |
| YF240A | 150*2 | SJZ65/132 | 400-500 | 90 | 10 | 0.8 |
Application:
Competitive Advantage:
This line features stable plasticity, high output, low sheering force, long life service, and other advantages.
The PVC profile production line consists of the control system, conical twin-screw extruder, calibration unit, haul-off unit, cutter, film covering machine and stacker.
The extruder is equipped with an advanced AC inverter, and an imported temperature controller (RKC, Japan).
The calibration unit’s vacuum pumps and haul-off unit’s motors are famous brand products.
